These are the docs for the Metabase master branch. Some features documented here may not yet be available in the latest release. Check out the docs for the latest version, Metabase v0.54.

Embedded analytics SDK - questions

Embedded analytics SDK is only available on Pro and Enterprise plans (both self-hosted and on Metabase Cloud). You can, however, play around with the SDK on your local machine without a license by using API keys to authenticate your embeds.

There are different ways you can embed questions:

Embedding a static question

You can embed a static question using the StaticQuestion component.

Docs: StaticQuestion

Static question

The component has a default height, which can be customized by using the height prop. To inherit the height from the parent container, you can pass 100% to the height prop.

import React from "react";
import {
  MetabaseProvider,
  StaticQuestion,
  defineMetabaseAuthConfig,
} from "@metabase/embedding-sdk-react";

const authConfig = defineMetabaseAuthConfig({
  metabaseInstanceUrl: "https://your-metabase.example.com",
  authProviderUri: "https://your-app.example.com/sso/metabase",
});

export default function App() {
  const questionId = 1; // This is the question ID you want to embed

  return (
    <MetabaseProvider authConfig={authConfig}>
      <StaticQuestion questionId={questionId} withChartTypeSelector={false} />
    </MetabaseProvider>
  );
}

Embedding an interactive question

You can embed an interactive question using the InteractiveQuestion component.

Docs: InteractiveQuestion

Interactive question

import React from "react";
import {
  InteractiveQuestion,
  MetabaseProvider,
  defineMetabaseAuthConfig,
} from "@metabase/embedding-sdk-react";

const authConfig = defineMetabaseAuthConfig({
  metabaseInstanceUrl: "https://your-metabase.example.com",
  authProviderUri: "https://your-app.example.com/sso/metabase",
});

export default function App() {
  const questionId = 1; // This is the question ID you want to embed

  return (
    <MetabaseProvider authConfig={authConfig}>
      <InteractiveQuestion questionId={questionId} />
    </MetabaseProvider>
  );
}

Pass SQL parameters to SQL questions with initialSqlParameters

You can pass parameter values to questions defined with SQL via the initialSqlParameters prop, in the format of {parameter_name: parameter_value}. Learn more about SQL parameters.

<StaticQuestion
  questionId={questionId}
  initialSqlParameters={{ product_id: 50 }}
/>

initialSqlParameters can’t be used with questions built using the query builder.

Customizing interactive questions

By default, the Embedded analytics SDK provides a default layout for interactive questions that allows you to view your questions, apply filters and aggregations, and access functionality within the query builder.

Here’s an example of using the InteractiveQuestion component with its default layout:

<InteractiveQuestion questionId={95} />

To customize the layout, use namespaced components within the InteractiveQuestion component. For example:

<div
  className="App"
  style={{
    width: "100%",
    maxWidth: "1600px",
    height: "800px",
    margin: "0 auto",
  }}
>
  <MetabaseProvider authConfig={authConfig} theme={theme}>
    <InteractiveQuestion questionId={95}>
      <div
        style={{
          display: "flex",
          flexDirection: "column",
          alignItems: "center",
          justifyContent: "center",
          width: "100%",
        }}
      >
        <div style={{ display: "grid", placeItems: "center", width: "100%" }}>
          <InteractiveQuestion.Title />
          <InteractiveQuestion.ResetButton />
        </div>
        <div
          style={{
            display: "flex",
            alignItems: "center",
            justifyContent: "flex-start",
            overflow: "hidden",
            width: "100%",
          }}
        >
          <div style={{ width: "100%" }}>
            <InteractiveQuestion.QuestionVisualization />
          </div>
          <div style={{ display: "flex", flex: 1, overflow: "scroll" }}>
            <InteractiveQuestion.Summarize />
          </div>
        </div>
        <div
          style={{ display: "flex", flexDirection: "column", width: "100%" }}
        >
          <InteractiveQuestion.Filter />
        </div>
      </div>
    </InteractiveQuestion>
  </MetabaseProvider>
</div>

Interactive question components

These components are available via the InteractiveQuestion namespace (e.g., <InteractiveQuestion.Filter />).

Docs:

Interactive question plugins

You can use plugins to add custom functionality to your questions.

mapQuestionClickActions

This plugin allows you to add custom actions to the click-through menu of an interactive question. You can add and customize the appearance and behavior of the custom actions.

// You can provide a custom action with your own `onClick` logic.
const createCustomAction = clicked => ({
  buttonType: "horizontal",
  name: "client-custom-action",
  section: "custom",
  type: "custom",
  icon: "chevronright",
  title: "Hello from the click app!!!",
  onClick: ({ closePopover }) => {
    alert(`Clicked ${clicked.column?.name}: ${clicked.value}`);
    closePopover();
  },
});

// Or customize the appearance of the custom action to suit your need.
const createCustomActionWithView = clicked => ({
  name: "client-custom-action-2",
  section: "custom",
  type: "custom",
  view: ({ closePopover }) => (
    <button
      className="tw-text-base tw-text-yellow-900 tw-bg-slate-400 tw-rounded-lg"
      onClick={() => {
        alert(`Clicked ${clicked.column?.name}: ${clicked.value}`);
        closePopover();
      }}
    >
      Custom element
    </button>
  ),
});

const plugins = {
  /**
   * You will have access to default `clickActions` that Metabase renders by default.
   * So you could decide if you want to add custom actions, remove certain actions, etc.
   */
  mapQuestionClickActions: (clickActions, clicked) => {
    return [
      ...clickActions,
      createCustomAction(clicked),
      createCustomActionWithView(clicked),
    ];
  },
};

const questionId = 1; // This is the question ID you want to embed

return (
  <MetabaseProvider authConfig={authConfig} pluginsConfig={plugins}>
    <InteractiveQuestion questionId={questionId} />
  </MetabaseProvider>
);

Prevent people from saving changes to an InteractiveQuestion

To prevent people from saving changes to an interactive question, or from saving changes as a new question, you can set isSaveEnabled={false}:

import React from "react";
import {
  InteractiveQuestion,
  MetabaseProvider,
  defineMetabaseAuthConfig,
} from "@metabase/embedding-sdk-react";

const authConfig = defineMetabaseAuthConfig({
  metabaseInstanceUrl: "https://your-metabase.example.com",
  authProviderUri: "https://your-app.example.com/sso/metabase",
});

export default function App() {
  return (
    <MetabaseProvider authConfig={authConfig}>
      <InteractiveQuestion questionId={1} isSaveEnabled={false} />
    </MetabaseProvider>
  );
}

Embedding the query builder for creating new questions

Query builder

You can embed the query builder for creating new questions by passing the questionId="new" prop to the InteractiveQuestion component. You can use the children prop to customize the layout for creating new questions.

import React from "react";
import {
  InteractiveQuestion,
  MetabaseProvider,
  defineMetabaseAuthConfig,
} from "@metabase/embedding-sdk-react";

const authConfig = defineMetabaseAuthConfig({
  metabaseInstanceUrl: "https://your-metabase.example.com",
  authProviderUri: "https://your-app.example.com/sso/metabase",
});

export default function App() {
  return (
    <MetabaseProvider authConfig={authConfig}>
      <InteractiveQuestion questionId="new" />
    </MetabaseProvider>
  );
}

To customize the question editor’s layout, use the InteractiveQuestion component directly with a custom children prop.

Read docs for other versions of Metabase.
